CM7560-564

API Delevan Inc.
RoHS
/
Package Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description Common Mode Filters / Chokes 560uH 25% .035ohm
PDF
/
Buying Options
Total Price: USD $46.4
Unit Price: USD $46.401825
≥1 USD $46.401825
≥200 USD $18.515829
≥500 USD $17.89614
≥1000 USD $17.590234
Inventory: 8390
Minimum: 1
-
+

Technical Details

Technical

Number of Functions 2
Depth 28.47mm
Lead Pitch 10.2mm
Inductance 560 μH
Test Frequency 1kHz
Max DC Current 3.5A
Lead/Base Style Pin
Filter Type DATA LINE FILTER
Number of Lines 2
DC Resistance (DCR) (Max) 35mOhm
Inductance @ Frequency 560μH @ 1kHz
Shielding Unshielded
HTS Code 8504.50.80.00
Terminal Finish Tin (Sn)
ECCN Code EAR99
Termination Radial
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code no
JESD-609 Code e3
Tolerance 25%
Size / Dimension 1.071Lx0.858W 27.20mmx21.80mm
Series CM7560
Published 2002
Packaging Bulk
Operating Temperature -55°C~125°C

Dimensions

Height 21.8694mm

Compliance

Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead

Physical

Core Material Ferrite
Package / Case Vertical, 4 PC Pin
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 8 Weeks
