CM6560-505
RoHS
/
Package Horizontal, 4 PC Pad
Category Filters / Common Mode Chokes
Description
CMC 5MH 950MA 2LN SMD
PDF
/
Buying Options
Total Price: USD $36.96
Unit Price: USD $36.955509
≥1 USD $36.955509
≥350 USD $14.74518
≥700 USD $14.252842
≥1050 USD $14.009956
Inventory: 1330
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Horizontal, 4 PC Pad
Core Material Ferrite
Technical
Operating Temperature -55°C~105°C
Packaging Tape & Reel (TR)
Published 2002
Series CM6560
Size / Dimension 0.630Lx0.630W 16.00mmx16.00mm
Tolerance 25%
JESD-609 Code e3
Pbfree Code no
Part Status Active
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Tin (Sn)
HTS Code 8504.50.80.00
Packing Method BULK; TR, 13 INCH
Shielding Unshielded
Number of Functions 2
Depth 16.25mm
Inductance 5 mH
Max DC Current 240mA
Filter Type DATA LINE FILTER
Rated Current 0.95A
Number of Lines 2
DC Resistance (DCR) (Max) 240mOhm
Current Rating (Max) 950mA
Inductance @ Frequency 5mH @ 10kHz
Dimensions
Diameter 15.8mm
Height 8.128mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
