CM6350-335
RoHS
/
Package Horizontal, 4 PC Pad
Category Filters / Common Mode Chokes
Description
Common Mode Filters / Chokes 3300uH 25% .55ohm Choke SMT Common
PDF
/
Buying Options
Total Price: USD $26.89
Unit Price: USD $26.892131
≥1 USD $26.892131
≥200 USD $10.730332
≥500 USD $10.37191
≥1000 USD $10.194669
Inventory: 2913
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Horizontal, 4 PC Pad
Core Material Ferrite
Technical
Operating Temperature -55°C~105°C
Packaging Bulk
Published 2002
Series CM6350
Size / Dimension 0.360Lx0.360W 9.14mmx9.14mm
Tolerance 25%
JESD-609 Code e3
Pbfree Code no
Part Status Active
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Tin (Sn)
HTS Code 8504.50.80.00
Packing Method TAPE AND REEL
Shielding Unshielded
Number of Functions 2
Depth 9.39mm
Inductance 3.3 mH
Max DC Current 400mA
Filter Type Power Line
Rated Current 0.4A
Number of Lines 2
DC Resistance (DCR) (Max) 550mOhm
Inductance @ Frequency 3.3mH @ 10kHz
Dimensions
Diameter 8.9mm
Height 5.334mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
