CM6149R-105
RoHS
RoHS compliant
RoHS compliantPackage Horizontal, 4 PC Pad
Category Filters / Common Mode Chokes
Description
Common Mode Chokes / Filters 1000uH 25% .25ohm Choke SMT Common
PDF
/
Buying Options
Total Price: USD $14.72
Unit Price: USD $14.7224
≥1 USD $14.7224
≥10 USD $13.9832
Inventory: 172
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Horizontal, 4 PC Pad
Core Material Ferrite
Technical
Operating Temperature -55°C~105°C
Packaging Tape & Reel (TR)
Published 2010
Series CM6149R
Size / Dimension 0.285Lx0.285W 7.24mmx7.24mm
Tolerance 25%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Tin (Sn)
HTS Code 8504.50.80.00
Packing Method TAPE AND REEL
Shielding Unshielded
Number of Functions 2
Depth 7.49mm
Inductance 1 mH
Current 400mA
Max DC Current 400mA
Filter Type DATA LINE FILTER
Number of Lines 2
DC Resistance (DCR) (Max) 250mOhm
Inductance @ Frequency 1mH @ 10kHz
Dimensions
Diameter 6.35mm
Height 5.334mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
