CM1011-104
RoHS
/
Package Horizontal, 4 PC Pin
Category Filters / Common Mode Chokes
Description
CMC 100UH 12A 2LN TH
PDF
/
Buying Options
Total Price: USD $27.76
Unit Price: USD $27.763896
≥1 USD $27.763896
≥200 USD $11.07825
≥500 USD $10.708012
≥1000 USD $10.525519
Inventory: 5565
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Horizontal, 4 PC Pin
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2002
Series CM1011
Size / Dimension 1.098Lx1.098W 27.90mmx27.90mm
Tolerance 25%
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
HTS Code 8504.50.80.00
Shielding Unshielded
Number of Functions 2
Inductance 100 μH
Filter Type DATA LINE FILTER
Number of Lines 2
DC Resistance (DCR) (Max) 4mOhm
Current Rating (Max) 12A
Inductance @ Frequency 100μH @ 1kHz
Dimensions
Height 18.5674mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
