CLJ-2-102
RoHS
RoHS compliant
RoHS compliantPackage Horizontal, 4 Flat Lead
Category Filters / Common Mode Chokes
Description
CMC 1MH 500MA 2LN SMD
PDF
/
Inventory: 5507
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height (Max) 0.146 3.70mm
Width 5.4102mm
Length 8.89mm
Height 3.7084mm
Technical
Inductance @ Frequency 1mH @ 100kHz
Current Rating (Max) 500mA
DC Resistance (DCR) (Max) 275mOhm Typ
Number of Lines 2
Current 500mA
Inductance 1 mH
Min Operating Temperature -25°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.350Lx0.213W 8.90mmx5.40mm
Series CLJ-2
Published 2008
Packaging Tape & Reel (TR)
Operating Temperature -25°C~85°C
Physical
Package / Case Horizontal, 4 Flat Lead
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
