ALFT-04-4
RoHS
RoHS compliant
RoHS compliantPackage Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
COMMON MODE CHOKE 1MH 4A 2LN TH
PDF
/
Buying Options
Total Price: USD $4.78
Unit Price: USD $4.7784
≥1 USD $4.7784
≥10 USD $3.86936
≥100 USD $3.439744
≥500 USD $3.24852
≥1000 USD $3.009688
≥3000 USD $2.96193
Inventory: 153
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Vertical, 4 PC Pin
Terminal Shape WIRE
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -25°C~85°C
Packaging Tray
Published 2008
Series ALFT-04
Size / Dimension 1.339Lx0.709W 34.00mmx18.00mm
Tolerance 20%
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Radial
ECCN Code EAR99
HTS Code 8504.50.80.00
Shielding NO
Number of Functions 2
Inductance 1 mH
Test Frequency 1kHz
Current 4A
Max DC Current 16A
Inductor Application COMMON MODE CHOKE
Lead/Base Style Pin
Inductor Type GENERAL PURPOSE INDUCTOR
Filter Type Signal Line
Number of Lines 2
DC Resistance (DCR) (Max) 10mOhm
Inductance @ Frequency 1mH @ 1kHz
Dimensions
Height 40.9956mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
