7704-3
RoHS
/
Package /
Category Connectors, Interconnects / Coaxial Connectors (RF)
Description
Tri-Loc? COMMERCIAL Nickel Gold Triaxial Connector 0.5GHz 75Ohm
PDF
/
Inventory: 7648
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Type Panel Mount
Mounting Feature Bulkhead - Rear Side Nut
Insulation Material TEFLON
Dielectric Material Polytetrafluoroethylene (PTFE)
Body Material Brass
Mounting Option 1 LOCKING
Center Contact Plating Gold
Center Contact Material Beryllium Copper
Technical
Packaging Bulk
Series Tri-Loc?
Part Status Active
ECCN Code EAR99
Connector Type Receptacle, Female Socket
Fastening Type Snap-On
Subcategory Other RF Connectors
Total Number of Contacts 1
Reliability COMMERCIAL
Housing Color Silver
Contact Style COAX
Impedance 75Ohm
Connector Style Triaxial
Number of Ports 1
Frequency (Max) 500MHz
Contact Termination Solder Cup
Includes 4 pcs - 1 Connector, 1 Cap, 1 Lockwasher, 1 Nut
Operating Frequency-Max 0.5GHz
Body Finish Nickel
Shield Termination Solder
