227726-1
RoHS
/
Package /
Category Connectors, Interconnects / Coaxial Connectors (RF)
Description
RF Connectors / Coaxial Connectors BULKHEAD SOLDER JACK
PDF
/
Inventory: 9183
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length 31.75mm
Technical
VSWR 1.3
Plating - Body Nickel
Frequency (Max) 4GHz
Withdrawl Force-Min .556 N
Insertion Force-Max 8.896 N
Durability 500 Cycles
Number of Ports 1
Impedance 50Ohm
ELV Non-Compliant
Body/Shell Style JACK
Insulation Resistance 5GOhm
Contact Style COAX
Polarity Normal, Standard
Reliability COMMERCIAL
Frequency 4GHz
Depth 13.08mm
Orientation Straight
Total Number of Contacts 1
Option GENERAL PURPOSE
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Fastening Type Bayonet
Additional Feature AMP
Voltage - Rated 500V
Gender Female
Color White
Min Operating Temperature -65°C
Max Operating Temperature 165°C
Number of Positions 1
Connector Type BNC
Termination Solder
Part Status Active
Pbfree Code no
JESD-609 Code e3
Published 2004
Packaging Bulk
Physical
Body Material Zinc
Insulation Material POLYBUTYLENE TEREPHTHALATE
Mount Panel
Contact Plating Tin
Contact Material Bronze
Supply Chain
Factory Lead Time 11 Weeks
