SMB5-J-P-H-RA-TH1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Coaxial Connectors (RF)
Description
Conn SMB F 0Hz to 4GHz 50Ohm Solder RA Thru-Hole Gold
PDF
/
Buying Options
Total Price: USD $8.18
Unit Price: USD $8.1752
≥1 USD $8.1752
≥10 USD $7.35944
≥100 USD $6.93264
≥500 USD $6.75488
≥1000 USD $6.57712
≥3000 USD $5.86608
Inventory: 2473
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Mount Through Hole
Mounting Type Panel Mount, Through Hole, Right Angle
Mounting Feature Bulkhead - Front Side Nut
Insulation Material Polytetrafluoroethylene
Dielectric Material Polytetrafluoroethylene (PTFE)
Body Material Brass
Center Contact Plating Gold
Technical
Operating Temperature -65°C~165°C
Packaging Tray
Published 2015
Series SMB5
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Jack, Male Pin
Gender Female
Voltage - Rated 250V
Fastening Type Snap-On
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Option GENERAL PURPOSE
Total Number of Contacts 1
Orientation Right Angle
Frequency 4GHz
Reliability COMMERCIAL
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Depth 0.805 inch
Contact Style COAX
Contact Resistance 6mOhm
Impedance 50Ohm
Connector Style SMB
Number of Ports 1
Contact Termination Solder
Includes 3 pcs - 1 Connector, 1 Lockwasher, 1 Nut
VSWR 1.5
Dimensions
Length 20.45mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Alternative Model
