GRF1-J-P-06-E-ST-TH1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Coaxial Connectors (RF)
Description
CONN MMCX JACK STR 50 OHM PCB
PDF
/
Buying Options
Total Price: USD $8.96
Unit Price: USD $8.9584
≥1 USD $8.9584
≥10 USD $7.94376
≥100 USD $7.638048
≥500 USD $7.332688
≥1000 USD $7.172
Inventory: 58
Minimum: 1
-
+
Technical Details
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Radiation Hardening No
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Brass, Copper
Mount Through Hole
Mounting Type Through Hole
Dielectric Material Polytetrafluoroethylene (PTFE)
Housing Material Plastic
Body Material Brass
Center Contact Plating Gold
Technical
Operating Temperature -40°C~90°C
Packaging Bulk
Published 2011
Series GRF1-J
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Jack, Female Socket
Number of Positions 6
Number of Rows 1
Gender Female
Voltage - Rated 500V
Fastening Type Snap-On
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Option GENERAL PURPOSE
Orientation Straight
Frequency 6GHz
Lead Pitch 5mm
Mating Information MULTIPLE MATING PARTS AVAILABLE
Coupling Type THREADED
Impedance 50Ohm
Connector Style MMCX
Contact Termination Solder
Dimensions
Height 4.6mm
Length 30mm
Width 5mm
