72970 image
Favorite
72970 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Coaxial Connectors (RF)
Description CONN SMA RCPT STR 50OHM EDGE MNT
PDF
/
Buying Options
Total Price: USD $7.09
Unit Price: USD $7.0928
≥1 USD $7.0928
Inventory: 332
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC No SVHC

Technical

Contact Termination Solder
Mating Cycles 500
Number of Ports 1
Connector Style SMA
Impedance 50Ohm
Termination Type SURFACE MOUNT
Body/Shell Style JACK
Polarity Standard
Frequency 18GHz
Orientation Straight
Option GENERAL PURPOSE
Filter Feature NO
IEC Conformance YES
DIN Conformance NO
MIL Conformance YES
Fastening Type Threaded
Voltage - Rated 500V
Connector Type Receptacle, Female Socket
ECCN Code EAR99
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Published 2008
Packaging Bulk
Operating Temperature -65°C~165°C

Physical

Center Contact Material Beryllium Copper
Center Contact Plating Gold
Body Material Brass
Dielectric Material Polytetrafluoroethylene (PTFE)
Insulation Material POLYTETRAFLUORO ETHYLENE
Mounting Type Board Edge, End Launch
Mount Edge
Contact Material Brass, Copper

Supply Chain

Factory Lead Time 2 Weeks
