0732510140
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Coaxial Connectors (RF)
Description
Conn SMA F 50Ohm ST Flange Mount Gold Tray
PDF
/
Inventory: 8120
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Contact Material Copper
Mount Flanges, Panel
Mounting Type Panel Mount
Mounting Feature Flange
Insulation Material Polytetrafluoroethylene
Dielectric Material Polytetrafluoroethylene (PTFE)
Body Material Stainless Steel
Center Contact Plating Gold
Center Contact Material Beryllium Copper
Technical
Operating Temperature -65°C~165°C
Packaging Tray
Series 73251
Feature EMI/RFI Gasket, Field Replaceable, For Hermetically Sealed Pin
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Receptacle, Female Socket
Gender Female
Voltage - Rated 500V
Fastening Type Threaded
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Option GENERAL PURPOSE
Orientation Straight
Depth 5mm
Reach Compliance Code unknown
Housing Color Silver
Body/Shell Style JACK
Impedance 50Ohm
Connector Style SMA
Number of Ports 1
Frequency (Max) 27GHz
Mating Cycles 500
Contact Termination Compression
Shield Termination Screw
Dimensions
Length 5mm
Compliance
RoHS Status ROHS3 Compliant
