PSA.0E.250.CTLC45Z
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Coaxial Connectors (RF)
Description
0E ROHS3Compliant Dust Tight IP66Water Resistant Waterproof IP68 - Dust Tight Waterproof Coaxial Connector 50Ohm -55C~200C
PDF
/
Inventory: 4434
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Dust Tight, IP66, Water Resistant, Waterproof
RoHS Status ROHS3 Compliant
Technical
Shield Termination Clamp
Cable Group RG-122, 174, 174A, 178B, 188A, 196A, 316B
Body Finish Chrome
Includes 3 pcs - 1 Connector, 1 Lockwasher, 1 Nut
Contact Termination Solder
Mating Cycles 5000
Connector Style Coaxial
Impedance 50Ohm
Housing Color Silver
Ingress Protection IP68 - Dust Tight, Waterproof
Fastening Type Push-Pull
Connector Type Receptacle, Female Socket
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 0E
Packaging Bulk
Operating Temperature -55°C~200°C
Physical
Center Contact Material Beryllium Copper
Center Contact Plating Gold
Body Material Brass
Dielectric Material Polytetrafluoroethylene (PTFE)
Mounting Feature Bulkhead - Rear Side Nut
Mounting Type Panel Mount
Mount Bulkhead, Panel, Rear Side Nut
Contact Material Copper
