PCA.00.250.CTLC31Z
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Coaxial Connectors (RF)
Description
Circular Push Pull Connectors COAX CABLE MT RECEPT FEMALE 3.1mm COLLET
PDF
/
Inventory: 1589
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Metal
Dielectric Material Polytetrafluoroethylene (PTFE)
Body Material Brass
Center Contact Plating Gold
Center Contact Material Bronze
Technical
Operating Temperature -55°C~260°C
Packaging Bulk
Series 00
Pbfree Code yes
Part Status Active
Connector Type Receptacle, Female Socket
Voltage - Rated 700V
Fastening Type Push-Pull
Contact Finish - Mating NOT SPECIFIED
Orientation Straight
Ingress Protection IP50 - Dust Protected
Contact Gender Female
Housing Color Silver
Impedance 50Ohm
Connector Style NIM-CAMAC CD/N 549
Number of Ports 1
Mating Cycles 5000
Contact Termination Solder
Body Finish Chrome
Cable Group RG-174A
Shield Termination Clamp
Compliance
RoHS Status ROHS3 Compliant
Ratings IP50
