UCBBJE20-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Coaxial Connectors (RF)
Description
CONN BNC JACK STR 75OHM EDGE MNT
PDF
/
Buying Options
Total Price: USD $4.28
Unit Price: USD $4.2768
≥1 USD $4.2768
≥10 USD $3.86672
≥100 USD $3.653056
≥500 USD $3.564
≥1000 USD $3.3858
≥3000 USD $3.029382
Inventory: 1164
Minimum: 1
-
+
Technical Details
Technical
Published 2012
Series 20
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Jack, Female Socket
Gender Female
Voltage - Rated 500V
Fastening Type Bayonet Lock
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Option GENERAL PURPOSE
Orientation Straight
Frequency 4GHz
Body/Shell Style RECEPTACLE
Impedance 75Ohm
Connector Style BNC
Number of Ports 1
Contact Termination Solder
Includes 3 pcs - 1 Connector, 1 Lockwasher, 1 Nut
Packaging Bulk
Operating Temperature -65°C~165°C
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
Physical
Center Contact Plating Gold
Body Material Brass
Dielectric Material Polytetrafluoroethylene (PTFE)
Material Nickel
Insulation Material Teflon
Mounting Feature Bulkhead - Front Side Nut
Mounting Type Board Edge, End Launch; Panel Mount
Mount Bulkhead, Edge, Panel, Through Hole
Contact Material Copper
Supply Chain
Factory Lead Time 8 Weeks
