RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Coaxial Connectors (RF)
Description
Coaxial Connector
PDF
/
Inventory: 924
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
Body Finish Nickel
Includes 3 pcs - 1 Connector, 1 Nut, 1 Washer
Contact Termination Solder
Mating Cycles 500
Number of Ports 1
Connector Style TRB, Twinaxial/Triaxial
Impedance Non-Constant
Body/Shell Style RECEPTACLE
Housing Color Silver
Frequency 500MHz
Orientation Straight
Option GENERAL PURPOSE
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Fastening Type Bayonet Lock
Voltage - Rated 400V
Connector Type Jack, Female Socket (Concentric)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Three Lug
Series 70
Published 2014
Packaging Bulk
Operating Temperature -65°C~165°C
Physical
Center Contact Material Beryllium Copper
Center Contact Plating Gold
Body Material Brass
Mounting Feature Bulkhead - Front Side Nut
Mounting Type Panel Mount, Through Hole
Mount Bulkhead, Panel, Through Hole
Contact Material Copper
Supply Chain
Factory Lead Time 8 Weeks
