RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Coaxial Connectors (RF)
Description
CONN TRS JACK STR SOLDER
PDF
/
Buying Options
Total Price: USD $40.64
Unit Price: USD $40.6384
≥1 USD $40.6384
≥10 USD $37.29528
≥100 USD $36.13896
Inventory: 110
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Copper
Mount Bulkhead, Flanges, Front Side Nut, Panel
Mounting Type Panel Mount
Mounting Feature Bulkhead - Front Side Nut
Insulation Material POLYTETRAFLUORO ETHYLENE
Body Material Brass
Center Contact Plating Gold
Center Contact Material Beryllium Copper
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Published 2012
Series 150
Feature Three Lug
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type Jack, Female Socket
Gender Female
Voltage - Rated 400V
Fastening Type Bayonet Lock
Contact Finish - Mating CADMIUM
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Option GENERAL PURPOSE
Orientation Straight
Frequency 500MHz
Housing Color Silver
Body Depth 0.592 inch
Body/Shell Style RECEPTACLE
Impedance Non-Constant
Connector Style TRS, Twinaxial/Triaxial
Number of Ports 1
Mating Cycles 500
Contact Termination Solder Cup
Includes 3 pcs - 1 Connector, 1 Nut, 1 Washer
Body Finish Nickel
Shield Termination Solder Tag
Dimensions
Length - Termination 0.402 inch
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
