FA1-NZSP-C01-0
RoHS
RoHS compliant
RoHS compliantPackage SMB
Category Connectors, Interconnects / Coaxial Connectors (RF)
Description
RF Connectors / Coaxial Connectors RG174 188 316 MALE ST FAKRA SMB
PDF
/
Buying Options
Total Price: USD $2.41
Unit Price: USD $2.411898
≥1 USD $2.411898
≥10 USD $2.275381
≥100 USD $2.146588
≥500 USD $2.02508
≥1000 USD $1.910454
Inventory: 8786
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Material Copper
Mount Flanges, Panel
Mounting Type Panel Mount
Package / Case SMB
Mounting Feature Flange
Insulation Material Teflon
Dielectric Material Polytetrafluoroethylene (PTFE)
Housing Material Polyester
Body Material Brass
Center Contact Plating Gold
Technical
Operating Temperature -40°C~100°C
Packaging Bulk
Published 2001
Feature Code Z
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Plug, Male Pin
Color Blue
Fastening Type Locking Ramp
Total Number of Contacts 1
Orientation Straight
Reach Compliance Code unknown
Reliability COMMERCIAL
Contact Gender FEMALE
Housing Color Blue, Water
Polarity Standard
Contact Style COAX
Impedance 50Ohm
Connector Style SMB, Fakra
Number of Ports 1
Frequency (Max) 4GHz
Mating Cycles 100
Contact Termination Crimp
Includes 3 pcs - 1 Connector, 1 Contact, 1 Ferrule
Insertion Loss 0.3dB
Body Finish Nickel
Cable Group RG-174, 188, 188A, 316, LMR-100, M17/119-RG174
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
