272105
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Coaxial Connectors (RF)
Description
Coaxial Connector
PDF
/
Buying Options
Total Price: USD $31.5
Unit Price: USD $31.504
≥1 USD $31.504
≥10 USD $27.58624
≥100 USD $26.394368
≥500 USD $25.543056
≥1000 USD $24.691656
≥3000 USD $23.329328
Inventory: 135
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Material Brass
Contact Plating Silver
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Insulation Material Polytetrafluoroethylene
Dielectric Material Polytetrafluoroethylene (PTFE)
Weight 105.099989g
Body Material Brass
Center Contact Plating Gold
Center Contact Material Brass
Technical
Operating Temperature -55°C~155°C
Packaging Bulk
Published 2008
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Plug, Male Pin
Max Operating Temperature 155°C
Min Operating Temperature -65°C
Fastening Type Threaded
Orientation Straight
Ingress Protection Weatherproof
Depth 32mm
Frequency 7.5GHz
Housing Color Silver
Impedance 50Ohm
Connector Style 7/16 DIN
Number of Ports 1
Body Plating Silver
Frequency (Max) 3GHz
Mating Cycles 500
Contact Termination Solder
Includes 3 pcs - 1 Connector, 1 Contact, 1 Ferrule
Body Finish White Bronze
Cable Group RG-8, 8A, 9, 87A, 213, 214, 225, 393
Shield Termination Crimp
Dimensions
Length 45.7mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
