182323
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Coaxial Connectors (RF)
Description
UHF, Mini Connector Plug, Male Pin 50 Ohm Free Hanging (In-Line), Right Angle Solder
PDF
/
Buying Options
Total Price: USD $7.79
Unit Price: USD $7.788
≥1 USD $7.788
≥10 USD $7.0092
≥100 USD $6.602816
≥500 USD $6.433504
≥1000 USD $6.264192
≥3000 USD $5.587006
Inventory: 134
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Material Brass
Contact Plating Gold
Mount Bulkhead, Cable, Free Hanging
Mounting Type Free Hanging (In-Line), Right Angle
Dielectric Material Polytetrafluoroethylene (PTFE)
Weight 10.300005g
Body Material Brass
Center Contact Plating Gold
Center Contact Material Brass
Technical
Operating Temperature -55°C~85°C
Packaging Bulk
Published 2008
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Plug, Male Pin
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Voltage - Rated 335V
Fastening Type Threaded
Orientation Right Angle
Frequency 300MHz
Housing Color Silver
Impedance 50Ohm
Connector Style UHF, Mini
Number of Ports 1
Body Plating Nickel
Frequency (Max) 2.5GHz
Mating Cycles 500
Contact Termination Solder
Includes 3 pcs - 1 Connector, 1 End Cap, 1 Ferrule
Body Finish Nickel
Cable Group RG-58, 58A, 58B, 58C, 141, 303, LMR-195, Belden B7806A, 9907
Shield Termination Crimp
Dimensions
Length 22.3mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
