142189-75
RoHS
RoHS compliant
RoHS compliantPackage SMB
Category Connectors, Interconnects / Coaxial Connectors (RF)
Description
SMB, Mini Connector Jack, Male Pin 75 Ohm Free Hanging (In-Line) Crimp
PDF
/
Buying Options
Total Price: USD $6
Unit Price: USD $6.0016
≥1 USD $6.0016
≥10 USD $5.4252
≥100 USD $5.124768
≥500 USD $4.999808
≥1000 USD $4.7498
≥3000 USD $4.249846
Inventory: 136
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Material Brass, Copper
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Package / Case SMB
Insulation Material Polytetrafluoroethylene
Dielectric Material Polytetrafluoroethylene (PTFE)
Body Material Brass
Center Contact Plating Gold
Technical
Operating Temperature -65°C~165°C
Packaging Bulk
Published 2003
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Jack, Male Pin
Gender Female
Voltage - Rated 335V
Fastening Type Snap-On
Total Number of Contacts 1
Orientation Straight
Frequency 4GHz
Reliability COMMERCIAL
Contact Style COAX
Impedance 75Ohm
Connector Style SMB, Mini
Number of Ports 1
Mating Cycles 500
Contact Termination Crimp
Insulator Color NATURAL
Includes 4 pcs - 1 Connector, 1 Contact, 1 Ferrule, 1 Heat Shrink
Insertion Loss 0.3dB
Cable Group RG-179, 187
Dimensions
Length 17.1mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
