142124
RoHS
RoHS compliant
RoHS compliantPackage SMB
Category Connectors, Interconnects / Coaxial Connectors (RF)
Description
Coaxial Connector
PDF
/
Inventory: /
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Brass, Copper
Contact Plating Gold
Mount Bulkhead, Cable, Front Side Nut, Panel
Mounting Type Panel Mount
Package / Case SMB
Mounting Feature Bulkhead - Front Side Nut
Dielectric Material Polytetrafluoroethylene (PTFE)
Body Material Brass
Center Contact Plating Gold
Center Contact Material Brass
Technical
Operating Temperature -65°C~165°C
Packaging Bulk
Published 2001
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Jack, Male Pin
Max Operating Temperature 165°C
Min Operating Temperature -65°C
Gender Female
Voltage - Rated 335V
Fastening Type Snap-On
Orientation Straight
Frequency 4GHz
Housing Color Silver
Impedance 50Ohm
Connector Style SMB
Number of Ports 1
Body Plating Nickel
Frequency (Max) 4GHz
Mating Cycles 500
Contact Termination Solder
Includes 9 pcs - 1 Connector, 1 Contact, 1 Clamp, 1 Gasket, 2 Insulators, 1 Nut, 1 Ring, 1 Washer
Insertion Loss 0.3dB
Body Finish Nickel
Cable Group RG-174, 188, 188A, 316, LMR-100, M17/119-RG174
Shield Termination Clamp
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
