132198

Amphenol RF
RoHS
RoHS RoHS compliant
Package SMA
Category Connectors, Interconnects / Coaxial Connectors (RF)
Description SMA Connector Jack, Female Socket 50 Ohm Free Hanging (In-Line) Solder
PDF
/
Buying Options
Total Price: USD $6.87
Unit Price: USD $6.8728
≥1 USD $6.8728
≥10 USD $6.21192
≥100 USD $5.868544
≥500 USD $5.725456
≥1000 USD $5.439104
≥3000 USD $4.866602
Inventory: 252
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 9 Weeks

Physical

Contact Material Copper
Contact Plating Gold
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Package / Case SMA
Insulation Material Polytetrafluoroethylene
Dielectric Material Polytetrafluoroethylene (PTFE)
Weight 3.399987g
Body Material Brass
Center Contact Plating Gold
Center Contact Material Beryllium Copper

Technical

Operating Temperature -65°C~165°C
Packaging Bulk
Published 2004
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Jack, Female Socket
Max Operating Temperature 165°C
Min Operating Temperature -65°C
Voltage - Rated 375V
Fastening Type Threaded
Orientation Straight
Ingress Protection Weatherproof
Depth 8mm
Frequency 12.4GHz
Housing Color Gold
Impedance 50Ohm
Connector Style SMA
Number of Ports 1
Body Plating Gold
Frequency (Max) 12.4GHz
Mating Cycles 500
Contact Termination Solder
Includes 4 pcs - 1 Connector, 1 Contact, 1 Ferrule, 1 Heat Shrink
Body Finish Gold
Cable Group RG-179, 188, 316 Double Braid, M17/152-RD316
Shield Termination Crimp

Dimensions

Length 19.8mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
