122391

Amphenol RF
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Coaxial Connectors (RF)
Description RF Connectors / Coaxial Connectors TNC ST CRIMP PLUG 75 OHM 3PC DL B8281
PDF
/
Inventory: 4141
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Length 25mm

Technical

Cable Group RG-59, Belden 1426A, 1505A, 8281, 9100, 9278
Body Finish Nickel
Insertion Loss 0.18dB
Includes 3 pcs - 1 Connector, 1 Contact, 1 Ferrule
Contact Termination Crimp
Terminal and Terminal Block Type BARRIER STRIP TERMINAL BLOCK
Mating Cycles 500
Frequency (Max) 1GHz
Number of Ports 1
Connector Style TNC
Impedance 75Ohm
Polarity Standard
Housing Color Silver
Frequency 11GHz
Orientation Straight
Fastening Type Threaded
HTS Code 8536.69.40.40
Voltage - Rated 500V
Min Operating Temperature -40°C
Max Operating Temperature 155°C
Connector Type Plug, Male Pin
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2006
Packaging Bulk

Physical

Center Contact Plating Gold
Body Material Brass
Dielectric Material Polyoxymethylene (POM) Acetal
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging

Supply Chain

Factory Lead Time 9 Weeks
