112405
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Coaxial Connectors (RF)
Description
BNC Connector Receptacle, Female Socket 75 Ohm Through Hole Solder
PDF
/
Buying Options
Total Price: USD $3.69
Unit Price: USD $3.6872
≥1 USD $3.6872
≥10 USD $3.35104
≥100 USD $3.173984
≥500 USD $3.10024
≥1000 USD $2.952664
≥3000 USD $2.583566
Inventory: 313
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Material Bronze
Contact Plating Gold
Mount PCB, Through Hole
Mounting Type Through Hole
Insulation Material Polytetrafluoroethylene
Dielectric Material Polytetrafluoroethylene (PTFE)
Weight 6.000006g
Body Material Brass
Center Contact Plating Gold
Center Contact Material Phosphor Bronze
Technical
Packaging Bulk
Published 2008
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Jack, Female Socket
Max Operating Temperature 165°C
Min Operating Temperature -65°C
Gender Female
Voltage - Rated 500V
Fastening Type Bayonet Lock
Orientation Straight
Frequency 1GHz
Housing Color Silver
Impedance 75Ohm
Connector Style BNC
Number of Ports 1
Body Plating Nickel
Frequency (Max) 4GHz
Mating Cycles 500
Contact Termination Solder
Body Finish Nickel
Shield Termination Solder
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
