082-6520

Amphenol RF
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Coaxial Connectors (RF)
Description Coaxial Connector
PDF
/
Buying Options
Total Price: USD $27.26
Unit Price: USD $27.2624
≥1 USD $27.2624
≥10 USD $23.87616
≥100 USD $22.844096
≥500 USD $22.10736
≥1000 USD $21.370448
≥3000 USD $20.191398
Inventory: 126
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant

Technical

Shield Termination Crimp
Cable Group Belden 9913, 9914, LMR-400
Body Finish Nickel
Insertion Loss 0.15dB
Includes 3 pcs - 1 Connector, 1 End Cap, 1 Ferrule
Contact Termination Solder
Mating Cycles 500
Frequency (Max) 6GHz
Body Plating Nickel
Number of Ports 1
Connector Style N Type
Impedance 50Ohm
Housing Color Silver
Fastening Type Threaded
Voltage - Rated 1500V
Min Operating Temperature -65°C
Max Operating Temperature 165°C
Resistance 50Ohm
Connector Type Plug, Male Pin
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2012
Packaging Bulk
Operating Temperature -65°C~165°C

Physical

Center Contact Material Brass
Center Contact Plating Gold
Body Material Brass
Dielectric Material Polytetrafluoroethylene (PTFE)
Mounting Type Free Hanging (In-Line), Right Angle
Mount Free Hanging
Contact Plating Gold
Contact Material Brass

Supply Chain

Factory Lead Time 8 Weeks
