031-6293
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Coaxial Connectors (RF)
Description
CONN RP-TNC JACK R/A 50 OHM PCB
PDF
/
Buying Options
Total Price: USD $11.02
Unit Price: USD $11.0176
≥1 USD $11.0176
≥10 USD $9.768
≥100 USD $9.392064
≥500 USD $9.01648
≥1000 USD $7.76417
≥3000 USD $7.263247
Inventory: 145
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Plating Gold
Mount Through Hole
Mounting Type Panel Mount, Through Hole, Right Angle
Mounting Feature Bulkhead - Front Side Nut
Dielectric Material Polytetrafluoroethylene (PTFE)
Body Material Zinc Die Cast
Center Contact Plating Gold
Center Contact Material Brass
Technical
Operating Temperature -65°C~165°C
Packaging Bulk
Published 2008
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Jack, Male Pin
Max Operating Temperature 165°C
Min Operating Temperature -65°C
Voltage - Rated 500V
Fastening Type Threaded
Housing Color Silver
Impedance 50Ohm
Connector Style RP-TNC
Number of Ports 1
Body Plating Tin
Frequency (Max) 1GHz
Mating Cycles 100
Contact Termination Solder
Body Finish Tin
Shield Termination Solder
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
