3284 image
Favorite
3284 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Coaxial Connectors (RF) - Adapters
Description CONN ADAPT JACK-JACK BNC 50 OHM
PDF
/
Buying Options
Total Price: USD $21.29
Unit Price: USD $21.2872
≥1 USD $21.2872
≥10 USD $20.933088
Inventory: 667
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC

Dimensions

Length 33.02mm

Technical

Adapter Series BNC to BNC, Dual
Gender Type A Female
Center Gender Female to Female
Adapter Type Jack to Jack
Conversion Type Same Series
Convert To (Adapter End) BNC Jack, Female Socket (2)
Convert From (Adapter End) BNC Jack, Female Socket
Operating Frequency-Max 4GHz
Impedance 50Ohm
Plating Nickel
Polarity Normal
Style T-Shape
Orientation Tee Style
Option GENERAL PURPOSE
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Fastening Type Bayonet Lock, Bayonet Lock
HTS Code 8536.69.80.00
Additional Feature SHIELDED
Voltage - Rated 500V
Resistance 50Ohm
Connector Type Coaxial
ECCN Code EAR99
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Published 2002
Packaging Bulk
Operating Temperature -65°C~165°C

Physical

Center Contact Material Beryllium Copper
Center Contact Plating Gold
Body Material Brass
Dielectric Material Polytetrafluoroethylene (PTFE)
Insulation Material Teflon
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper

Supply Chain

Factory Lead Time 2 Weeks
