242232

Amphenol RF
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Coaxial Connectors (RF) - Adapters
Description CONN ADAPT BNC JACK TO TNC PLUG
PDF
/
Buying Options
Total Price: USD $22.73
Unit Price: USD $22.7304
≥1 USD $22.7304
≥10 USD $19.90208
≥100 USD $19.041792
≥500 USD $18.427552
≥1000 USD $17.813224
≥3000 USD $16.830414
Inventory: 156
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 10 Weeks

Physical

Contact Material Brass, Bronze
Contact Plating Gold
Mount Free Hanging
Mounting Type Free Hanging (In-Line), Right Angle
Insulation Material Polytetrafluoroethylene
Dielectric Material Polytetrafluoroethylene (PTFE)
Body Material Brass
Center Contact Plating Gold
Center Contact Material Brass; Phosphor Bronze

Technical

Operating Temperature -65°C~165°C
Packaging Bulk
Published 2009
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Fastening Type Bayonet Lock, Threaded
Orientation Right Angle
Depth 14.5mm
Style Right Angle
Frequency 4GHz
Polarity Normal
Plating Nickel
Impedance 50Ohm
Body Plating Nickel
Frequency (Max) 4GHz
Body Finish Nickel
Convert From (Adapter End) BNC Jack, Female Socket
Convert To (Adapter End) TNC Plug, Male Pin
Conversion Type Between Series
Adapter Type Plug to Jack
Center Gender Female to Male
Gender Type A Female
Adapter Series BNC to TNC
Gender Type B Male

Dimensions

Length 27.3mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
