9463 00310000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cables, Wires / Coaxial Cables (RF)
Description
78 OHM TWINAX ;ROHS COMPLIANT: YES
PDF
/
Inventory: 970
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Insulation Material PE
Dielectric Material Polyethylene (PE)
Conductor Material Copper, Tinned
Jacket (Insulation) Material Poly-Vinyl Chloride (PVC)
Shield Material Aluminum; Copper, Tinned
Technical
Operating Temperature -40°C~80°C
Series Blue Hose?
Feature Drain Wire, Oil Resistant, UV Resistant
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Resistance 0.031Ohm
Shielding YES
Construction STRANDED
Reach Compliance Code compliant
Number of Conductors 2
Approval Agency CE; CEC; CUL; NEC; UL
Wire Gauge 20 AWG
Connector Support Type WIRE AND CABLE
Cable Type Twinaxial
Impedance 78Ohm
Jacket Color Orange
Conductor Strand 7 Strands / 28 AWG
Jacket (Insulation) Diameter 0.238 (6.05mm)
Shield Type Foil, Braid
Shield Coverage 100%, 55%
Rated Voltage 300V
Stranding 7X28
Wire and Cable Name COMMUNICATION CABLE
Dielectric Diameter 0.078 (1.98mm)
VoP, Velocity of Propagation 66
Dimensions
Length 10000' 3048.00m
Compliance
RoHS Status RoHS Compliant
