9269 010500
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cables, Wires / Coaxial Cables (RF)
Description
COAX RG-62A/U 22AWG 93 OHM
PDF
/
Buying Options
Total Price: USD $679.13
Unit Price: USD $679.125096
≥1 USD $679.125096
Inventory: 5877
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length 500.0' 152.40m
Technical
VoP, Velocity of Propagation 84
Dielectric Diameter 0.146 (3.71mm)
Cable Group RG-62A
Shield Coverage 95%
Shield Type Braid
Jacket (Insulation) Diameter 0.239 (6.07mm)
Conductor Strand Solid
Jacket Color Black
Impedance 93Ohm
Cable Type Coaxial
Wire Gauge 22 AWG
Reach Compliance Code compliant
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Operating Temperature -40°C~80°C
Physical
Shield Material Copper, Bare
Jacket (Insulation) Material Poly-Vinyl Chloride (PVC)
Conductor Material Steel, Copper Coated
Dielectric Material Semi Solid Polyethylene (SSPE)
Supply Chain
Factory Lead Time 3 Weeks
