M4206 BK002
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cables, Wires / Coaxial Cables (RF)
Description
CABLE COAXIAL RG8A 11AWG 500'
PDF
/
Inventory: 1
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Dielectric Material Cellular (Foam) Polyethylene (Cellular FPE)
Conductor Material Copper, Bare
Jacket (Insulation) Material Poly-Vinyl Chloride (PVC)
Shield Material Copper, Bare
Technical
Operating Temperature -40°C~80°C
Published 2009
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Wire Gauge 11 AWG (4.60mm2)
Connector Support Type WIRE AND CABLE
Cable Type Coaxial
Impedance 50Ohm
Jacket Color Black
Conductor Strand 7 Strands / 19 AWG
Jacket (Insulation) Diameter 0.403 (10.24mm)
Shield Type Braid
Shield Coverage 96%
Cable Group RG-8A
Dielectric Diameter 0.285 (7.24mm)
VoP, Velocity of Propagation 78
Dimensions
Length 500.0' 152.40m
Compliance
RoHS Status ROHS3 Compliant
