9178B BR005
RoHS
/
Package /
Category Cables, Wires / Coaxial Cables (RF)
Description
CABLE COAXIAL RG178B 30AWG 100'
PDF
/
Inventory: 7562
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Dielectric Material Tetrafluoroethylene (TFE)
Conductor Material Steel, Silver Coated
Jacket (Insulation) Material Fluorinated Ethylene-Propylene (FEP)
Shield Material Copper, Silver Coated
Technical
Published 2009
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Wire Gauge 30 AWG (0.06mm2)
Cable Type Coaxial
Impedance 50Ohm
Jacket Color Brown
Conductor Strand 7 Strands / 38 AWG
Jacket (Insulation) Diameter 0.071 (1.80mm)
Shield Type Braid
Shield Coverage 96%
Cable Group RG-178B
Dielectric Diameter 0.034 (0.86mm)
VoP, Velocity of Propagation 70
Dimensions
Length 100.0' 30.48m
