M48T58Y-70MH1F
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.337, 8.56mm Width) with SNAPHAT Sockets
Category Integrated Circuits (ICs) / Clock/Timing - Real Time Clocks
Description
28-SOIC (0.337 8.56mm Width) with SNAPHAT Sockets M48T58 8542.39.00.01 Leap Year rtc clock circuit 4.5V~5.5V 3mA @ 4.5V~5.5V 18.1mm 70GHz
PDF
/
Buying Options
Total Price: USD $13.43
Unit Price: USD $13.4288
≥1 USD $13.4288
≥10 USD $12.34024
≥100 USD $11.82896
≥500 USD $10.422368
≥1000 USD $9.910877
Inventory: 480
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 8.56mm
Length 18.1mm
Height Seated (Max) 3.05mm
Technical
Volatile NO
Interrupt Capability N
Time-Min SECONDS
Current - Timekeeping (Max) 3mA @ 4.5V~5.5V
Date Format YY-MM-DD-dd
Time Format HH:MM:SS (24 hr)
External Data Bus Width 8
Logic Function Clock
Access Time 70 ns
Memory Size 62.5kB
Interface Parallel
Power Supplies 5V
Operating Supply Voltage 5V
Pin Count 28
Base Part Number M48T58
Time@Peak Reflow Temperature-Max (s) 30
Frequency 70GHz
Terminal Pitch 1.27mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 245
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology CMOS
Subcategory Timer or RTC
HTS Code 8542.39.00.01
Type Clock/Calendar
ECCN Code EAR99
Number of Terminations 28
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Feature Leap Year
JESD-609 Code e3
Series Timekeeper?
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Number of Pins 28
Package / Case 28-SOIC (0.337, 8.56mm Width) with SNAPHAT Sockets
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 26 Weeks
