M48T37V-10MH1F
RoHS
RoHS compliant
RoHS compliantPackage 44-BSOP (0.337, 8.56mm Width) requires SNAPHAT
Category Integrated Circuits (ICs) / Clock/Timing - Real Time Clocks
Description
44-BSOP (0.337 8.56mm Width) requires SNAPHAT M48T37 8542.39.00.01 Alarm Leap Year Watchdog Timer real time clock IC 3V~3.6V 2mA @ 3V~3.6V 18.1mm 100GHz
PDF
/
Buying Options
Total Price: USD $20.03
Unit Price: USD $20.0288
≥1 USD $20.0288
≥10 USD $18.47384
≥100 USD $17.643296
≥500 USD $15.775232
≥1000 USD $15.048739
Inventory: 788
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 26 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 44-BSOP (0.337, 8.56mm Width) requires SNAPHAT
Number of Pins 44
Technical
Operating Temperature 0°C~70°C
Packaging Tape & Reel (TR)
Series Timekeeper?
JESD-609 Code e3
Feature Alarm, Leap Year, Watchdog Timer
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 44
ECCN Code EAR99
Type Clock/Calendar
HTS Code 8542.39.00.01
Subcategory Timer or RTC
Technology CMOS
Voltage - Supply 3V~3.6V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 245
Supply Voltage 3.3V
Terminal Pitch 0.81mm
Frequency 100GHz
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number M48T37
Pin Count 44
Operating Supply Voltage 3.3V
Interface Parallel
Memory Size 250kB
Number of Bits 8
Access Time 100 ns
Logic Function Clock
External Data Bus Width 8
Time Format HH:MM:SS (24 hr)
Date Format YY-MM-DD-dd
Current - Timekeeping (Max) 2mA @ 3V~3.6V
Time-Min SECONDS
Interrupt Capability Y
Volatile NO
Dimensions
Height Seated (Max) 3.05mm
Length 18.1mm
Width 8.56mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
