DS1672-33
RoHS
/
Package 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Clock/Timing - Real Time Clocks
Description
DUAL Binary I2C Obsolete Real Time Clock (RTC) IC -40C~85C 0.032MHz 9.375mm 500muA @ 3.63V
PDF
/
Buying Options
Total Price: USD $12.08
Unit Price: USD $12.0821
≥1 USD $12.0821
≥10 USD $9.91325
≥100 USD $9.60355
≥500 USD $9.29385
≥1000 USD $8.98415
Inventory: 102
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Through Hole
Package / Case 8-DIP (0.300, 7.62mm)
Surface Mount NO
Technical
Operating Temperature -40°C~85°C
Packaging Tube
JESD-609 Code e0
Feature Trickle-Charger
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 8
Type Binary Counter
Terminal Finish TIN LEAD
Voltage - Supply 2.97V~3.63V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 240
Supply Voltage 3.3V
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) 20
Pin Count 8
JESD-30 Code R-PDIP-T8
Qualification Status COMMERCIAL
Interface I2C, 2-Wire Serial
Clock Frequency 0.032MHz
Time Format Binary
Current - Timekeeping (Max) 500μA @ 3.63V
Voltage - Supply, Battery 1.3V~3.63V
Information Access Method I2C
Dimensions
Height Seated (Max) 4.572mm
Length 9.375mm
Width 7.62mm
Compliance
RoHS Status Non-RoHS Compliant
