DS1374U-33
RoHS
/
Package 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Real Time Clocks
Description
DUAL Binary CMOS Obsolete Real Time Clock (RTC) IC -40C~85C 3mm 175muA @ 2.97V~5.5V 2.97V~5.5V
PDF
/
Buying Options
Total Price: USD $5.37
Unit Price: USD $5.37035
≥1 USD $5.37035
≥10 USD $4.4061
≥100 USD $4.26835
≥500 USD $4.1306
≥1000 USD $3.99285
Inventory: 1158
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 3mm
Length 3mm
Height Seated (Max) 1.1mm
Technical
Voltage - Supply, Battery 1.3V~5.5V
Current - Timekeeping (Max) 175μA @ 2.97V~5.5V
Time Format Binary
Adjustable Threshold NO
Interface I2C, 2-Wire Serial
Number of Channels 1
Supply Voltage-Min (Vsup) 2.97V
Supply Voltage-Max (Vsup) 5.5V
JESD-30 Code S-PDSO-G10
Pin Count 10
Time@Peak Reflow Temperature-Max (s) 20
Reach Compliance Code unknown
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 240
Terminal Position DUAL
Voltage - Supply 2.97V~5.5V
Technology CMOS
Terminal Finish TIN LEAD
Type Binary Counter
Number of Terminations 10
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Feature Alarm, Square Wave Output, Trickle-Charger, Watchdog Timer
JESD-609 Code e0
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
