DS1306N
RoHS
/
Package 16-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Clock/Timing - Real Time Clocks
Description
DUAL HH:MM:SS (12/24hr) SERIAL 3-WIRE Obsolete Real Time Clock (RTC) IC 96B -40C~85C 0.032MHz 19.175mm
PDF
/
Inventory: 7720
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 7.62mm
Length 19.175mm
Height Seated (Max) 4.572mm
Technical
Information Access Method SERIAL, 3-WIRE
Voltage - Supply, Battery 2V~5.5V
Current - Timekeeping (Max) 25.3μA~81μA @ 2V~5V
Date Format YY-MM-DD-dd
Time Format HH:MM:SS (12/24 hr)
Clock Frequency 0.032MHz
Memory Size 96B
Interface SPI
Qualification Status COMMERCIAL
JESD-30 Code R-PDIP-T16
Pin Count 16
Time@Peak Reflow Temperature-Max (s) 20
Reach Compliance Code unknown
Terminal Pitch 2.54mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 240
Terminal Position DUAL
Voltage - Supply 2V~5.5V
Terminal Finish TIN LEAD
Type Clock/Calendar
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Feature Alarm, Leap Year, NVSRAM, Square Wave Output, Trickle-Charger
JESD-609 Code e0
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Surface Mount NO
Package / Case 16-DIP (0.300, 7.62mm)
Mounting Type Through Hole
