DS1305EN/T&R
RoHS
/
Package 20-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Real Time Clocks
Description
HH:MM:SS (12/24hr) Obsolete Clock/Calendar Surface Mount Real Time Clock (RTC) IC 96B -40C~85C 25.3muA~81muA @ 2V~5V 2V~5.5V
PDF
/
Inventory: 9314
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 20-TSSOP (0.173, 4.40mm Width)
Supplier Device Package 20-TSSOP
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Feature Alarm, Leap Year, NVSRAM, Trickle-Charger
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Clock/Calendar
Voltage - Supply 2V~5.5V
Interface SPI
Memory Size 96B
Time Format HH:MM:SS (12/24 hr)
Date Format YY-MM-DD-dd
Current - Timekeeping (Max) 25.3μA~81μA @ 2V~5V
Voltage - Supply, Battery 2V~5.5V
Compliance
RoHS Status Non-RoHS Compliant
