MCP79411T-I/MS
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Real Time Clocks
Description
8-TSSOP 8-MSOP (0.118 3.00mm Width) MCP79411 e3 Alarm Leap Year Square Wave Output SRAM Unique ID real time clock IC 1.8V~5.5V 1.2muA @ 3.3V 3mm 0.4MHz
PDF
/
Buying Options
Total Price: USD $1.04
Unit Price: USD $1.042443
≥1 USD $1.042443
≥200 USD $0.404373
≥500 USD $0.389931
≥1000 USD $0.383367
Inventory: 1159
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 3mm
Length 3mm
Height Seated (Max) 1.1mm
Technical
Information Access Method I2C
Volatile NO
Voltage - Supply, Battery 1.3V~5.5V
Interrupt Capability Y
Time-Min SECONDS
Current - Timekeeping (Max) 1.2μA @ 3.3V
Date Format YY-MM-DD-dd
Time Format HH:MM:SS (12/24 hr)
Logic Function Clock
Clock Frequency 0.4MHz
Memory Size 64B 1Kb
Interface I2C, 2-Wire Serial
Power Supplies 2/5V
Pin Count 8
Base Part Number MCP79411
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.65mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 1.8V~5.5V
Technology CMOS
Subcategory Timers or RTCs
Terminal Finish Matte Tin (Sn) - annealed
Type Clock/Calendar
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Alarm, Leap Year, Square Wave Output, SRAM, Unique ID
JESD-609 Code e3
Published 2007
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 8
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 7 Weeks
