DS3231MZ/V+
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Real Time Clocks
Description
8-SOIC (0.154 3.90mm Width) DS3231 e3 Alarm Leap Year Square Wave Output rtc clock circuit 2.3V~5.5V 130muA~200muA @ 3.63V~5.5V 4.9mm -40C~85C
PDF
/
Buying Options
Total Price: USD $9.01
Unit Price: USD $9.0112
≥1 USD $9.0112
≥10 USD $8.14088
≥100 USD $7.761952
≥500 USD $6.739568
≥1000 USD $6.436698
≥3000 USD $5.868755
Inventory: 646
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 3.9mm
Length 4.9mm
Height Seated (Max) 1.75mm
Technical
Information Access Method I2C
Volatile NO
Voltage - Supply, Battery 2.3V~5.5V
Interrupt Capability Y
Time-Min SECONDS
Current - Timekeeping (Max) 130μA~200μA @ 3.63V~5.5V
Date Format YY-MM-DD-dd
Time Format HH:MM:SS (12/24 hr)
Number of Timers 1
Logic Function Clock
Operating Supply Current 300μA
Interface I2C, 2-Wire Serial
Operating Supply Voltage 3.3V
Pin Count 8
Base Part Number DS3231
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 1.27mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 2.3V~5.5V
Technology CMOS
Subcategory Timer or RTC
Terminal Finish Matte Tin (Sn)
Type Clock/Calendar
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
Pbfree Code yes
Feature Alarm, Leap Year, Square Wave Output
JESD-609 Code e3
Series Automotive, AEC-Q100
Published 2012
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 540.001716mg
Number of Pins 8
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
