DS17885E-5+

Maxim Integrated
RoHS
RoHS RoHS compliant
Package 28-TSSOP (0.465, 11.80mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Real Time Clocks
Description 28-TSSOP (0.465 11.80mm Width) DS17885 R-PDSO-G28 Alarm Daylight Savings Leap Year NVSRAM Square Wave Output rtc clock circuit 4.5V~5.5V 3mA @ 4.5V~5.5V 11.8mm 0.032MHz
PDF
/
Buying Options
Total Price: USD $15.39
Unit Price: USD $15.387679
≥1 USD $15.387679
≥10 USD $14.516676
≥100 USD $13.694982
≥500 USD $12.91979
≥1000 USD $12.188481
Inventory: 1378
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Width 8mm
Length 11.8mm
Height Seated (Max) 1.2mm

Technical

Volatile YES
Voltage - Supply, Battery 2.5V~3.7V
Interrupt Capability Y
Time-Min SECONDS
Current - Timekeeping (Max) 3mA @ 4.5V~5.5V
Date Format YY-MM-DD-dd
Time Format HH:MM:SS (12/24 hr)
Number of Timers 1
External Data Bus Width 8
Clock Frequency 0.032MHz
Memory Size 8KB
Interface Parallel
Power Supplies 5V
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G28
Pin Count 28
Base Part Number DS17885
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.55mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology CMOS
Subcategory Timer or RTC
HTS Code 8542.39.00.01
Terminal Finish Matte Tin (Sn)
Type Clock/Calendar
ECCN Code EAR99
Number of Terminations 28
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
Feature Alarm, Daylight Savings, Leap Year, NVSRAM, Square Wave Output
JESD-609 Code e3
Published 2000
Packaging Tray
Operating Temperature 0°C~70°C

Physical

Surface Mount YES
Package / Case 28-TSSOP (0.465, 11.80mm Width)
Mounting Type Surface Mount
