DS1685-5
RoHS
/
Package 24-DIP (0.600, 15.24mm)
Category Integrated Circuits (ICs) / Clock/Timing - Real Time Clocks
Description
DUAL HH:MM:SS (12/24hr) CMOS Obsolete Real Time Clock (RTC) IC 2002 SECONDS 242B 0C~70C
PDF
/
Inventory: 5771
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case 24-DIP (0.600, 15.24mm)
Surface Mount NO
Technical
Operating Temperature 0°C~70°C
Packaging Tube
Published 2002
JESD-609 Code e0
Feature Alarm, NVSRAM, Square Wave Output, Y2K
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 24
ECCN Code EAR99
Type Clock/Calendar
Terminal Finish Tin/Lead (Sn/Pb)
HTS Code 8542.39.00.01
Subcategory Timer or RTC
Technology CMOS
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 240
Supply Voltage 5V
Terminal Pitch 2.54mm
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 20
Base Part Number DS1685
Pin Count 24
JESD-30 Code R-PDIP-T24
Qualification Status Not Qualified
Power Supplies 5V
Interface Parallel
Memory Size 242B
Clock Frequency 0.032MHz
External Data Bus Width 8
Number of Timers 1
Time Format HH:MM:SS (12/24 hr)
Date Format YY-MM-DD-dd
Current - Timekeeping (Max) 3mA @ 5V
Time-Min SECONDS
Voltage - Supply, Battery 2.5V~3.7V
Volatile YES
Dimensions
Height Seated (Max) 5.08mm
Length 31.75mm
Width 15.24mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead, Lead Free
