SN74LV221APWTE4
RoHS
/
Package TSSOP
Category Integrated Circuits (ICs) / Clock/Timing - Programmable Timers and Oscillators
Description
IC DUAL MONO MULTIVIB 16-TSSOP
PDF
/
Inventory: 7939
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Package / Case TSSOP
Number of Pins 16
Weight 61.887009mg
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Moisture Sensitivity Level (MSL) 1
Number of Terminations 16
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Supply Voltage 2.5V
Terminal Pitch 0.65mm
Pin Count 16
Operating Supply Voltage 5V
Temperature Grade INDUSTRIAL
Max Supply Voltage 5.5V
Min Supply Voltage 2V
Current - Output 12mA
Propagation Delay 44 ns
Quiescent Current 20μA
Turn On Delay Time 14 ns
Family LV/LV-A/LVX/H
Logic Function Multivibrator
Output Polarity COMPLEMENTARY
High Level Output Current -12mA
Low Level Output Current 12mA
Independent Circuits 2
Schmitt Trigger Input Yes
Number of Data/Clock Inputs 2
Dimensions
Length 5mm
Width 4.4mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Contains Lead
