SN74AHCT123ADE4
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / Clock/Timing - Programmable Timers and Oscillators
Description
IC MULTIVIBRATOR DUAL 16-SOIC
PDF
/
Inventory: 5319
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Package / Case SOIC
Number of Pins 16
Weight 141.690917mg
Technical
JESD-609 Code e4
Pbfree Code yes
Moisture Sensitivity Level (MSL) 1
Number of Terminations 16
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Additional Feature EDGE TRIGGERED FROM ACTIVE-HIGH OR ACTIVE-LOW GATED LOGIC INPUTS
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Supply Voltage 5V
Pin Count 16
Operating Supply Voltage 5V
Power Supplies 5V
Temperature Grade INDUSTRIAL
Max Supply Voltage 5.5V
Min Supply Voltage 4.5V
Current - Output 8mA
Propagation Delay 15 ns
Quiescent Current 4μA
Turn On Delay Time 11 ns
Family AHCT/VHCT/VT
Logic Function Multivibrator
Output Polarity COMPLEMENTARY
High Level Output Current -8mA
Low Level Output Current 8mA
Independent Circuits 2
Schmitt Trigger Input Yes
Number of Data/Clock Inputs 2
Dimensions
Height Seated (Max) 1.75mm
Length 9.9mm
Width 3.9mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Contains Lead
