LMC555CBPX
RoHS
/
Package /
Category Integrated Circuits (ICs) / Clock/Timing - Programmable Timers and Oscillators
Description
INDUSTRIAL BOTTOM Tin/Lead (Sn63Pb37) CMOS programmable timer -40C 12V 1 3MHz
PDF
/
Buying Options
Total Price: USD $0.52
Unit Price: USD $0.5192
≥1 USD $0.5192
Inventory: 1625
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Length 1.412mm
Technical
Output Frequency-Max 3MHz
Analog IC - Other Type PULSE; RECTANGULAR
Supply Voltage-Min (Vsup) 1.5V
Temperature Grade INDUSTRIAL
Power Supplies 5V
Supply Voltage-Max (Vsup) 12V
Operating Temperature (Min) -40°C
Qualification Status Not Qualified
Pin Count 8
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.5mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form BALL
Terminal Position BOTTOM
Technology CMOS
Subcategory Analog Waveform Generation Functions
Terminal Finish Tin/Lead (Sn63Pb37)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1
Pbfree Code no
JESD-609 Code e0
Physical
Number of Pins 8
Surface Mount YES
