MC100EP196BMNR4G
RoHS
RoHS compliant
RoHS compliantPackage 32-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description
ACTIVE DELAY LINE NO LEAD Programmable MATTE TIN delay line IC -40C~85C 3V 2.5ns 5mm
PDF
/
Inventory: 2300
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 5mm
Length 5mm
Technical
Tap Increment 10ps
Total Delay-Nom (td) 12.4 ns
Available Total Delays 2.5ns ~ 13ns
Programmable Delay Line YES
Delay to 1st Tap 2.5ns
Number of Independent Delays 1
Number of Taps/Steps 1024
Logic IC Type ACTIVE DELAY LINE
Output Polarity COMPLEMENTARY
Supply Voltage-Min (Vsup) 3V
Supply Voltage-Max (Vsup) 3.6V
Qualification Status COMMERCIAL
Function Programmable
JESD-30 Code S-XQCC-N32
Time@Peak Reflow Temperature-Max (s) 40
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 3V~3.6V
Technology ECL
Additional Feature NECL MODE: VCC=0 WITH VEE=-3.0 V TO -3.6 V
Terminal Finish MATTE TIN
Number of Terminations 32
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series 100EP
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 32-VFQFN Exposed Pad
Mounting Type Surface Mount
