MC100EP195FA
RoHS
/
Package /
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description
ACTIVE DELAY LINE GULL WING TIN LEAD ECL delay line IC 3V 12.2ns 7mm
PDF
/
Buying Options
Total Price: USD $24.88
Unit Price: USD $24.8843
≥1 USD $24.8843
≥10 USD $20.41835
≥100 USD $19.77995
≥500 USD $19.1425
≥1000 USD $18.5041
Inventory: 10001
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 7mm
Length 7mm
Height Seated (Max) 1.6mm
Technical
Total Delay-Nom (td) 12.2 ns
Programmable Delay Line YES
Number of Taps/Steps 1023
Logic IC Type ACTIVE DELAY LINE
Output Polarity COMPLEMENTARY
Supply Voltage-Min (Vsup) 3V
Temperature Grade INDUSTRIAL
Supply Voltage-Max (Vsup) 3.6V
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Qualification Status COMMERCIAL
JESD-30 Code S-PQFP-G32
Pin Count 32
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.8mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Terminal Position QUAD
Technology ECL
Additional Feature NECL MODE: VCC=0 WITH VEE= -3.0V TO -3.6V
Terminal Finish TIN LEAD
Number of Terminations 32
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e0
Series 100EP
Physical
Surface Mount YES
