DS1135LZ-12
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description
SILICON DELAY LINE GULL WING Multiple NonProgrammable TIN LEAD delay line IC 2.7V 12ns 4.9mm
PDF
/
Buying Options
Total Price: USD $6.59
Unit Price: USD $6.5912
≥1 USD $6.5912
Inventory: 1078
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Technical
Packaging Tube
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Terminal Finish TIN LEAD
Voltage - Supply 2.7V~3.6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 245
Supply Voltage 3.3V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PDSO-G8
Function Multiple, NonProgrammable
Qualification Status COMMERCIAL
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Temperature Grade INDUSTRIAL
Supply Voltage-Min (Vsup) 2.7V
Output Polarity TRUE
Logic IC Type SILICON DELAY LINE
Output Impedance 50Ohm
Number of Taps/Steps 1
Number of Independent Delays 3
Delay to 1st Tap 12ns
Programmable Delay Line NO
Total Delay-Nom (td) 12 ns
Dimensions
Height Seated (Max) 1.75mm
Length 4.9mm
Compliance
RoHS Status Non-RoHS Compliant
